  • Product description:
  • INQUIRY
Display Size 9.7"
Style True Flat
Monitor Dimensions 360 x 280 x 50 mm
LCD Type TFT LCD(LED backlight)
Useful Screen Area 196.7 mm x 148.3 mm
Aspect Ratio 4：3
Optimal (native) Resolution 1024x768
LCD Panel Pixel Pitch 0.192x0.192 mm
LCD Panel Colors Arrangement RGB-Stripe
LCD Panel Brightness 300 cd/m2
Contrast Ratio 800 : 1
LCD Panel Response Time 25 ms
Viewing Angle Horizontal ±85°(left/right) or 170° total
(typical, from center) vertical ±85°(left/right) or 170° total
Power Supply Type Monitor Input: +12VDC ±5%,5.0 A; DC Jack (2.5 (t) AC to DC Power Brick Input: 100-240 VAC, 50/60 Hz  Power Consumption: Less Than10W
Backlight Lamp Life Typical 20,000 hours
video input
Connector VGA or HDMI Optional
Temperature Operating: -0°C to 40°C:Storage -10°C to 50°C
Humidity (non-condensing) Operating: 20%-80%; Storage: 10%-90%
Weight (approx.) Actual: 1.4 kg ;
Warranty Monitor 3 Years(Except for LCD panel 1 year)
Mounting Options 75mm VESA mount
Accessories VGA cable: 1. 5M, not including stand and adaptor.
