System |
Processor |
Intel®J1900/j4125/2.00GHz（optional） |
|
Memory |
8Gb standard, DDR4 |
|
|
Storage |
SSD 128Gb |
|
|
Operation System |
Windows 10/11, |
|
Display |
Type |
15” LED back light |
|
Resolution |
1024x768@60Hz/ | |
|
Brightness |
350 cd/m2 |
|
|
Touchscreen |
Projected capacitive touchscreen |
|
Interfaces |
Display |
HDMI*1 |
|
USB |
USB2.0*4, USB 3.0*2 |
|
|
Serial |
RS232*1(Optional) |
|
|
Audio |
LIN_OUT*1, MIC_IN*1 |
|
|
Power |
DC 12V/5A |
|
Others |
Operation Temperature |
0℃ to ±65℃ |
|
Storage Temperature |
－20℃ to ＋65℃ |
|
|
Dimensions(L*W*H) |
351*275*49.5mm |
|
|
Weight |
5KG |
|
|
Warranty |
3 years for whole machine, 1 year for LCD panel |
